    Referencing the circuit above the unknown PT is a Ferguson PVD105, specs exist online so finding a suitable replacement isn't difficult not that one is required.

    I have written to Evacto about a turret board to replace the cracked and broken circuit board and once that is sorted I'll start ordering bits.

  3. #33
    Overlord of Music DrNomis_44's Avatar
    Join Date
    Dec 2014
    Location
    Darwin,NT Australia
    Posts
    4,852
    Quote Originally Posted by dave.king1 View Post
    Referencing the circuit above the unknown PT is a Ferguson PVD105, specs exist online so finding a suitable replacement isn't difficult not that one is required.

    I have written to Evacto about a turret board to replace the cracked and broken circuit board and once that is sorted I'll start ordering bits.

    Making a custom Turret board isn't that hard to do, although you do need some simple tools for installing the Turrets, last time I visited the Evatco website they had all the materials and tools in stock needed to make Turret boards, you could use the old board (it looks like a Fender-style eyelet board) as a guide, and then draw a layout on some paper, note that I have never in my whole life made a Turret board so I'm no expert, but I wouldn't mind learning how to make them myself.

  4. #34
    Overlord of Music dave.king1's Avatar
    Join Date
    Aug 2014
    Location
    Sutherland Shire
    Posts
    2,465
    Quote Originally Posted by DrNomis_44 View Post
    Making a custom Turret board isn't that hard to do, although you do need some simple tools for installing the Turrets, last time I visited the Evatco website they had all the materials and tools in stock needed to make Turret boards, you could use the old board (it looks like a Fender-style eyelet board) as a guide, and then draw a layout on some paper, note that I have never in my whole life made a Turret board so I'm no expert, but I wouldn't mind learning how to make them myself.
    I'm entirely with you on this, if I can design and build a car I'm sure I can copy a simple cct board that I have in front of me

    It can't be that difficult, mind you I won't finish up with the rats nest that currently passes as P-P wiring
