This has been sitting on the bench since early this year and will probably sit there a while longer as I had all the bits for the bass first so i started that.
It's kustom ordered with soapbar P90 pick up routs. So far the trem and tuners have arrived. Trying to decide on pick ups and colour now.
I've got to finish my one of these too deddy
I'm intrigued, never seen anything like that.
Mmmm, P90's!
Finally kicked myself in the bum and got into this. Have done a black timbermate fill and sand and blue ink stain. I've tried a silicone liquid mask again on the binding, see how it goes. Will do the black burst next, then the frets, then glue the neck in.
Attachment 33095
Attachment 33096
Burst done, frets done, neck attached. Body staining tomorrow
Attachment 33119
Looking good Deddy, I'm still going on mine and I think its been over a year now!
Dude, I finished mine just on a year ago now. Yours must be like 2 years cooking now.Quote:
Originally Posted by Andy40
Can't wait to see this finished @Dedman looks the bizz
Nice work.
How'd you go with the silicone mask? Was it less work than tape? Better/cleaner result?
Enquiring minds want to know!
Well, the silicone is easier to apply I guess. it defiantly seals the edges, is easy to get off. Overall, slightly better than tape in my opinion.
I used this one as I had it on hand for my scale modelling.
Attachment 33124
tidy up, then clear coats to come.
Attachment 33125
Attachment 33135Quote:
Originally Posted by Dedman
Hah!!! LIQUID FRISKET!!! Band name alert!
How do you apply it? Small artist's brush?
Are you able to mask the narrow top edge of the binding?
yea for the F holes I used a really small brush 02 size, you can just rub the stuff off with your finger tip afterwards
Cool - thanks!
Clear coats are on. On the home straight now
Attachment 33171
And done! Still has chinese strings while the neck settles, then I'll put on something better and set the intonation but she sounds great, nice and twangy with the Tone Rider Rebel 90's. I used 500k pots and a .47 cap and a treble bleed so it does sound quite dark, ....just the way I like it :D. The Duesenburg Les Trem is the second one I've fitted to a build and I love them, so light to the touch.
I'm calling this the P90RS and I'll do better and more pics outside when it isn't so freaking hot.
Attachment 33206
Sweet! ...but I'm more taken with the Fender blackface & tweed lunch boxes in the background!!!
I want...
Ebay purchases, just the thing to keep spare strings and the like in :DQuote:
Originally Posted by McCreed
Looking good Dedman. Any chance of a sound demo? Curious to hear what it sounds like. I’m only familiar with the .022uF cap.
Looking so great mate. Well done.
The cap value only really makes a difference when you turn the tone control down a bit. Any slight difference it will make with the tone control right up is a very small fraction of a decibel at higher frequencies, so basically inaudible. With 500k pots, if it sounds dark, then it will be down to the pickups themselves and the guitar's construction rather than the choice of tone cap.
My standard tone is playing with the tone turned towards the bass end just short of sounding muddy.Quote:
Originally Posted by Simon Barden
Then it certainly is important to you. I was wondering if Dedman turned down the tone control at all in normal use?
I actually made an error in my post, the pots are 250k, the cap was correct at .047. Generally I leave the tone pot around the middle and never touch it
Perfect, that's what most manufactures recommend for their P90 pups. Pretty much treat em as per any other single coil.
500k is the standard P90 pot value, so 250k will make them a bit darker. And 250k will already have an effect on the tone as there's less resistance between the capacitor and the signal before you even start to turn the pot down. So yes, I understand now that it will sound darker than normal.
