Logo Sizes

Can someone who has an F guitar measure the actual height of the letter F and the overall width of the word that starts with F and ends in ender?

I am trying to mock up a Rabbitz logo but want it roughly the dimensions of the original.

I understand there are about 5 different F logo's but anyone will do for my purposes.

TIA

Rabz

heres a few options mate...

original 50s/60s spaghetti design, F height 30mm, overall length 60mm

http://img.photobucket.com/albums/v7...psrt5mj8c6.jpg

09 artist series strat (transition style logo)

35mm F height, overall length 55mm

http://img.photobucket.com/albums/v7...psxsysa8az.jpg

80s archtop!

25mm F height, overall length 45mm

http://img.photobucket.com/albums/v7...pshwdreshb.jpg

Thanks ZM.

That gives me all the info I need.

The original spaghetti logo really appeals to me. Just a pity there is no F and no E in Rabbitz ;)

So here are a couple of ideas:

Attachment 5496

Attachment 5499

Attachment 5500

Also I was toying with "REPROCASTER" for the model name.

One last try for tonight:

Attachment 5503

There is an actual Fender font you can download off the interwebz Rabbitz, try hunting around a bit if you haven't already. Logos look good!

Thanks, I actually got hold of that font after I knocked these together, I will experiment later. Brush Script MT does OK if you play with the kerning, tracking, baseline shift, mix fonts sizes, angles etc. (sounds a lot but isn't that hard in a vector program).

I found it here:
http://www.liamalexander.com/blog/twitter/fender-font/

It looks like he has created and collected a collection of "corporate" fonts. Handy site.

The Reprocaster font is Myriad Pro - Adobe Illustrator defaults to this. It is the first time in 8 or 10 years I've actually used the default font in anger :)

OK I am hopeless, here it is in Fender Font.

Attachment 5507

If you compare it closely the only significant change is the hook on the R. The rest is exactly the same as Brush Script MT Italic. I think the only changes are to upper case and possibly lower case e.

Mmmm I do like Brush Script, I've used it on some stuff myself!

I read an interesting little note (not sure if its true or not) about the original spaghetti... apparently it's just Leo's handwriting with the "F" flipped backwards
